Turbine Flow Meter

Ultrasonic Flow Meter

Ultrasonic Flow Meter Specification

Flow Rate
Display in m/h, L/min, etc.

Protection
IP65

Temperature Range
-30C to +160C (sensor dependent)

Connectivity Type
RS485, 4-20mA, Relay Output

Measurement Range
0-99999 m/h

Sensor Type
Clamp-on / Insertion / Inline

Capacity
Optimal for industrial and municipal pipelines

Humidity %
0-95% RH

Current Range
4-20mA output

Frequency
1 MHz / 2 MHz (sensor dependent)

Application Media
Liquid (Water, Sewage, Oil, Chemicals)

Pressure Range
Standard atmospheric to 1.6MPa

Resolution
0.001 m/s

Equipment Type
Ultrasonic Flow Meter

Diameter
DN15~DN6000

Material
ABS / Aluminium Alloy

Power Supply
220V AC / 24V DC

Power Consumption
<3W

Accuracy
1% of reading

Display Type
LCD Digital Display

Range
0.1~20 m/s

Cable Length
Standard 5m (Customizable)

Mounting Type
Wall Mount / Panel Mount / Portable

Weight
About 2.5kg (Main Unit)

Menu Language
Multi-language Support

Output Signal
Pulse, 4-20mA, RS485

Installation Conditions
Non-intrusive, No Pressure Drop

Transducer Material
Stainless Steel / Plastic

Interface
Keypad

Data Logger
Built-in/Optional

Response Time
< 3 seconds

Ultrasonic Flow Meter Trade Information

Minimum Order Quantity
1 Number

Supply Ability
10 Per Day

Delivery Time
6 Week

About Ultrasonic Flow Meter

Ultrasonic Display Flow Meter proposed by us utilizes sound waves for the determination the velocity of a fluid flowing in a pipe. The meter is suitable for wastewater usages or any dirty liquid which is water based or conductive but will commonly not work with drinking water or distilled water. Made from wide display, powder coated metal housing, and other hi-tech contact components, Ultrasonic Display Flow Meter is easy to install, reliable, low maintenance, and can be availed in varied models and sizes at reasonable prices.

Technical fact sheet of Ultrasonic flow meter -

Principle: Transit time measurement.
Sensor: Clamp on type , Mounted on pipeline, V path measurement OR Insertion sensor
Best suitable for 50-1000mm dia pipe.
Time measurement Resolution : 0.1ns
Lcd Display : Flow rate + Total + RS232 o/p

Advanced Accuracy and Versatility

Engineered for accuracy within 1% of reading, this ultrasonic flow meter is tailored to diverse industrial and municipal applications. Its expansive measurement range (0.1-20 m/s) and adaptability-covering diameters from DN15 to DN6000-enable reliable operation across various pipeline systems and fluid types.

Effortless, Non-intrusive Installation

This flow meter supports non-intrusive installation methods, ensuring there's no pressure drop or pipeline modification required. The clamp-on, insertion, or inline sensor types-combined with a standard 5m cable (customizable)-allow for seamless integration, fast setup, and minimal operational disruption.

User-friendly Operation & Integration

Intuitive keypad interface and LCD display make setup and monitoring straightforward. Multi-language menu support enhances usability, while pulse, 4-20mA, and RS485 outputs facilitate direct integration with automation or monitoring systems. The device accommodates both wall/panel mount and portable deployments for flexible use.

FAQ's of Ultrasonic Flow Meter:

Q: How does the non-intrusive installation process work for this ultrasonic flow meter?

A: The meter's clamp-on, insertion, or inline sensor options allow it to be installed externally on the pipe, eliminating the need to cut or modify the pipeline. This ensures no contact with the liquid and prevents any pressure drop, providing quick and simple setup without interrupting operations.

Q: What benefits does the built-in data logger provide?

A: The built-in or optional data logger records flow data over time, enabling detailed analysis and historical tracking of flow trends. This is especially beneficial for performance audits, compliance reporting, or diagnosing fluctuations within municipal or industrial systems.

Q: When is it ideal to use this ultrasonic flow meter in an industrial or municipal context?

A: It is well-suited for continuous flow monitoring of liquids such as water, sewage, oil, and chemicals in large-scale pipelines (DN15~DN6000). Its robust construction and IP65 protection ensure reliability under demanding environmental conditions or where frequent recalibration is impractical.

Q: Where can this ultrasonic flow meter be mounted?

A: The device supports wall, panel, and portable mounting types, making it flexible for fixed installations in control rooms, on-site mounting at pipeline locations, or temporary use during maintenance and troubleshooting activities.

Q: What output and connectivity options does this flow meter support for integration?

A: It features multiple output signals-pulse, 4-20mA, and RS485-enabling seamless integration with control, monitoring, or data acquisition systems. Relay output is also supported, enhancing compatibility with industrial automation setups.

Q: How user-friendly is the meter for operators with diverse language needs?

A: With a multi-language menu interface and a tactile keypad, users from different regions or language backgrounds can easily configure and operate the device. The clear LCD digital display further simplifies readings and diagnostics.

Q: What is the typical process for customizing the cable length or choosing sensor material?

A: Upon ordering, users can specify custom cable lengths according to site requirements. For transducer material, stainless steel is recommended for harsh or corrosive fluids, while plastic may suit less aggressive environments-both ensuring optimal service life and measurement performance.
